PowerShell .NET and GUI Interfaces

by Lewis · Sat 5th April, 2014

I’ve been grabbing a bit of software from Technet (you know, that thing that Microsoft are shutting down! <_<) and with their download links, they provide SHA1 hashes of the ISOs. I had a quick look around the web for something that allowed you to get SHA1 hashes of files and while I found a few, I didn’t find any that would allow you to provide a hash and compare the resultant hash with the one you’re given by the provider so I decided to write one myself and as with any opportunity, I decided to use PowerShell and .NET with Windows Forms to create a GUI interface as opposed to it all being text based. Sacrilege to those PowerShell purists but it’s a limited feature tool and I wanted to learn something new so here’s the code.

Function Get-FileName($initialDirectory)
{
 [System.Reflection.Assembly]::LoadWithPartialName("System.Windows.Forms") |  Out-Null

 $OpenFileDialog = New-Object System.Windows.Forms.OpenFileDialog
 $OpenFileDialog.initialDirectory = $initialDirectory
 $OpenFileDialog.filter = "All files (*.*)| *.*"

 $OpenFileDialog.ShowDialog() | Out-Null
 $OpenFileDialog.filename
} #end function Get-FileName

#We're going to draw a form.
[System.Reflection.Assembly]::LoadWithPartialName("System.Windows.Forms") | Out-Null

#Open a GUI for the user to select the file.
$Filename = Get-FileName -initialDirectory "C:\"

# Check that the path is correct
If (!(Test-Path $Filename)) { Exit }

# Create Input Data (Read the file)
$File = [System.IO.File]::Open($Filename, "open", "read")

# Create a New SHA1 Crypto Provider
$Sha1 = New-Object System.Security.Cryptography.SHA1CryptoServiceProvider

# Output the hash (converted to Hex)
$Hash = [String]::Concat(($Sha1.ComputeHash($File) | % { $_.ToString("x2") }))

#[System.Windows.Forms.MessageBox]::Show("$Hash", "SHA1 Hash", 0)

# Create a GUI Form
$objForm = New-Object System.Windows.Forms.Form
$objForm.Text = "SHA1 Hash Calculator/Comparison Tool"
$objForm.MaximumSize = $objForm.MinimumSize = $objForm.Size = New-Object System.Drawing.Size(400,250)
$objForm.MaximizeBox = $objForm.MinimizeBox = $false
$objForm.StartPosition = "CenterScreen"

# Add a label
$oTitle = New-Object System.Windows.Forms.Label
$oTitle.Location = New-Object System.Drawing.Size(5,5)
$oTitle.Size = New-Object System.Drawing.Size(385,40)
$oTitle.Text = "The calculated hash for your selected file is shown below. You can paste a known hash and compare the two by clicking the compare button."
$objForm.Controls.Add($oTitle)

#File Label
$oFileLabel = New-Object System.Windows.Forms.Label
$oFileLabel.Location = New-Object System.Drawing.Size(5,(53))
$oFileLabel.Size = New-Object System.Drawing.Size(105,20)
$oFileLabel.Text = "File:"
$objForm.Controls.Add($oFileLabel)

# Add a Textbox
$oFileTB = New-Object System.Windows.Forms.TextBox
$oFileTB.Location = New-Object System.Drawing.Size(($oFileLabel.Left + $oFileLabel.Width + 5),($oFileLabel.Top -3))
$oFileTB.Size = New-Object System.Drawing.Size(265,20)
$oFileTB.Text = $Filename.ToString()
$oFileTB.ReadOnly = $true
$objForm.Controls.Add($oFileTB)

# Add a Richtextbox
#$oTitle = New-Object System.Windows.Forms.RichTextBox
#$oTitle.Location = New-Object System.Drawing.Size(0,0)
#$oTitle.Size = New-Object System.Drawing.Size(385,45)

#$oTitle.Rtf = "{\rtf1\ansi\ansicpg1252\deff0\nouicompat\deflang2057{\fonttbl{\f0\fnil\fcharset0 Microsoft Sans Serif;}{\f1\fnil\fcharset0 Calibri;}}
#{\*\generator Riched20 6.3.9600}\viewkind4\uc1
#\pard\sa200\sl276\slmult1\f0\fs16\lang9 The calculated hash for your selected file \b ("+$Filename.Replace("\", "\\")+")\b0  is shown below. You can paste a known hash and compare the two by clicking the compare button.\f1\fs22\par
#}"
#$oTitle.ScrollBars = "None"
#$oTitle.ReadOnly = $True

#$objForm.Controls.Add($oTitle)

# Add a label
$objLabel = New-Object System.Windows.Forms.Label
$objLabel.Location = New-Object System.Drawing.Size(5,(53+50)) # Everything elses location is calculated in reference to this.
$objLabel.Size = New-Object System.Drawing.Size(105,20)
$objLabel.Text = "Calculated SHA1:"
#$objLabel.TextAlign = "MiddleRight"
$objForm.Controls.Add($objLabel)

# Add another label
$objLabel2 = New-Object System.Windows.Forms.Label
$objLabel2.Text = "Comparison SHA1:"
#$objLabel2.TextAlign = "MiddleRight"
$objLabel2.Location = New-Object System.Drawing.Point ($objLabel.Left, ($objLabel.Height + $objLabel.Top + 10))
$objLabel2.Size = New-Object System.Drawing.Size(105,20)
$objForm.Controls.Add($objLabel2)

# Add a Textbox
$objTextBox = New-Object System.Windows.Forms.TextBox
$objTextBox.Location = New-Object System.Drawing.Size(($objLabel.Left + $objLabel.Width + 5),($objLabel.Top -3))
$objTextBox.Size = New-Object System.Drawing.Size(265,20)
$objTextBox.Text = $Hash
$objTextBox.ReadOnly = $true
$objForm.Controls.Add($objTextBox)

# Add comparison box
$objSuppliedVal = New-Object System.Windows.Forms.TextBox
$objSuppliedVal.Location = New-Object System.Drawing.Point ($ObjTextBox.Left, ($objTextBox.Height + $objTextBox.Top + 10))
$objSuppliedVal.Size = New-Object System.Drawing.Size(265,20)
$objForm.Controls.Add($objSuppliedVal)

# Add an Exit button
$ExitButton = New-Object System.Windows.Forms.Button
#$ExitButton.Location = New-Object System.Drawing.Size(300,100)
$ExitButton.Location = New-Object System.Drawing.Point (($ObjTextBox.Right - 75), ($objSuppliedVal.Height + $objSuppliedVal.Top + 10))
$ExitButton.Size = New-Object System.Drawing.Size(75,23)
$ExitButton.Text = "Exit"
#$ExitButton.Add_Click({$objForm.Close()})
$objForm.CancelButton = $ExitButton
$objForm.Controls.Add($ExitButton)

# Add compare button
$CompareButton = New-Object System.Windows.Forms.Button
$CompareButton.Location = New-Object System.Drawing.Point (($ExitButton.Left - $ExitButton.Width - 10), ($objSuppliedVal.Height + $objSuppliedVal.Top + 10))
#$CompareButton.Location = New-Object System.Drawing.Size($ExitButton.Left - $ExitButton.Width - 10,100)
$CompareButton.Size = New-Object System.Drawing.Size(75,23)
$CompareButton.Text = "Compare"
$CompareButton.Add_Click({

    $SuppliedValue = $objSuppliedVal.Text.ToLower()
    $CalculatedValue = $objTextBox.Text.ToLower()

    $MsgBoxButtons = New-Object System.Windows.Forms.MessageBoxButtons
    $MsgBoxIcon = New-Object System.Windows.Forms.MessageBoxIcon

    If ($SuppliedValue -eq $CalculatedValue) {

        $MsgBoxButtons = "OK"
        $MsgBoxIcon = "Information"

        [System.Windows.Forms.MessageBox]::Show("Matched successfully.", "Success", $MsgBoxButtons, $MsgBoxIcon)

    }
    Else {

        $MsgBoxButtons = "OK"
        $MsgBoxIcon = "Warning"

        [System.Windows.Forms.MessageBox]::Show("Not matched.", "Not matched", $MsgBoxButtons, $MsgBoxIcon)

    }

})
$objForm.Controls.Add($CompareButton)

$objForm.Topmost = $true
$objForm.ShowDialog()

# Clear up
$File.Dispose()

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

Function Get-FileName($initialDirectory)

{

[System.Reflection.Assembly]::LoadWithPartialName("System.Windows.Forms") | Out-Null

$OpenFileDialog = New-Object System.Windows.Forms.OpenFileDialog

$OpenFileDialog.initialDirectory = $initialDirectory

$OpenFileDialog.filter = "All files (*.*)| *.*"

$OpenFileDialog.ShowDialog() | Out-Null

$OpenFileDialog.filename

} #end function Get-FileName

#We're going to draw a form.

[System.Reflection.Assembly]::LoadWithPartialName("System.Windows.Forms") | Out-Null

#Open a GUI for the user to select the file.

$Filename = Get-FileName -initialDirectory "C:\"

# Check that the path is correct

If (!(Test-Path $Filename)) { Exit }

# Create Input Data (Read the file)

$File = [System.IO.File]::Open($Filename, "open", "read")

# Create a New SHA1 Crypto Provider

$Sha1 = New-Object System.Security.Cryptography.SHA1CryptoServiceProvider

# Output the hash (converted to Hex)

$Hash = [String]::Concat(($Sha1.ComputeHash($File) | % { $_.ToString("x2") }))

#[System.Windows.Forms.MessageBox]::Show("$Hash", "SHA1 Hash", 0)

# Create a GUI Form

$objForm = New-Object System.Windows.Forms.Form

$objForm.Text = "SHA1 Hash Calculator/Comparison Tool"

$objForm.MaximumSize = $objForm.MinimumSize = $objForm.Size = New-Object System.Drawing.Size(400,250)

$objForm.MaximizeBox = $objForm.MinimizeBox = $false

$objForm.StartPosition = "CenterScreen"

# Add a label

$oTitle = New-Object System.Windows.Forms.Label

$oTitle.Location = New-Object System.Drawing.Size(5,5)

$oTitle.Size = New-Object System.Drawing.Size(385,40)

$oTitle.Text = "The calculated hash for your selected file is shown below. You can paste a known hash and compare the two by clicking the compare button."

$objForm.Controls.Add($oTitle)

#File Label

$oFileLabel = New-Object System.Windows.Forms.Label

$oFileLabel.Location = New-Object System.Drawing.Size(5,(53))

$oFileLabel.Size = New-Object System.Drawing.Size(105,20)

$oFileLabel.Text = "File:"

$objForm.Controls.Add($oFileLabel)

# Add a Textbox

$oFileTB = New-Object System.Windows.Forms.TextBox

$oFileTB.Location = New-Object System.Drawing.Size(($oFileLabel.Left + $oFileLabel.Width + 5),($oFileLabel.Top -3))

$oFileTB.Size = New-Object System.Drawing.Size(265,20)

$oFileTB.Text = $Filename.ToString()

$oFileTB.ReadOnly = $true

$objForm.Controls.Add($oFileTB)

# Add a Richtextbox

#$oTitle = New-Object System.Windows.Forms.RichTextBox

#$oTitle.Location = New-Object System.Drawing.Size(0,0)

#$oTitle.Size = New-Object System.Drawing.Size(385,45)

#$oTitle.Rtf = "{\rtf1\ansi\ansicpg1252\deff0\nouicompat\deflang2057{\fonttbl{\f0\fnil\fcharset0 Microsoft Sans Serif;}{\f1\fnil\fcharset0 Calibri;}}

#{\*\generator Riched20 6.3.9600}\viewkind4\uc1

#\pard\sa200\sl276\slmult1\f0\fs16\lang9 The calculated hash for your selected file \b ("+$Filename.Replace("\", "\\")+")\b0 is shown below. You can paste a known hash and compare the two by clicking the compare button.\f1\fs22\par

#}"

#$oTitle.ScrollBars = "None"

#$oTitle.ReadOnly = $True

#$objForm.Controls.Add($oTitle)

# Add a label

$objLabel = New-Object System.Windows.Forms.Label

$objLabel.Location = New-Object System.Drawing.Size(5,(53+50)) # Everything elses location is calculated in reference to this.

$objLabel.Size = New-Object System.Drawing.Size(105,20)

$objLabel.Text = "Calculated SHA1:"

#$objLabel.TextAlign = "MiddleRight"

$objForm.Controls.Add($objLabel)

# Add another label

$objLabel2 = New-Object System.Windows.Forms.Label

$objLabel2.Text = "Comparison SHA1:"

#$objLabel2.TextAlign = "MiddleRight"

$objLabel2.Location = New-Object System.Drawing.Point ($objLabel.Left, ($objLabel.Height + $objLabel.Top + 10))

$objLabel2.Size = New-Object System.Drawing.Size(105,20)

$objForm.Controls.Add($objLabel2)

# Add a Textbox

$objTextBox = New-Object System.Windows.Forms.TextBox

$objTextBox.Location = New-Object System.Drawing.Size(($objLabel.Left + $objLabel.Width + 5),($objLabel.Top -3))

$objTextBox.Size = New-Object System.Drawing.Size(265,20)

$objTextBox.Text = $Hash

$objTextBox.ReadOnly = $true

$objForm.Controls.Add($objTextBox)

# Add comparison box

$objSuppliedVal = New-Object System.Windows.Forms.TextBox

$objSuppliedVal.Location = New-Object System.Drawing.Point ($ObjTextBox.Left, ($objTextBox.Height + $objTextBox.Top + 10))

$objSuppliedVal.Size = New-Object System.Drawing.Size(265,20)

$objForm.Controls.Add($objSuppliedVal)

# Add an Exit button

$ExitButton = New-Object System.Windows.Forms.Button

#$ExitButton.Location = New-Object System.Drawing.Size(300,100)

$ExitButton.Location = New-Object System.Drawing.Point (($ObjTextBox.Right - 75), ($objSuppliedVal.Height + $objSuppliedVal.Top + 10))

$ExitButton.Size = New-Object System.Drawing.Size(75,23)

$ExitButton.Text = "Exit"

#$ExitButton.Add_Click({$objForm.Close()})

$objForm.CancelButton = $ExitButton

$objForm.Controls.Add($ExitButton)

# Add compare button

$CompareButton = New-Object System.Windows.Forms.Button

$CompareButton.Location = New-Object System.Drawing.Point (($ExitButton.Left - $ExitButton.Width - 10), ($objSuppliedVal.Height + $objSuppliedVal.Top + 10))

#$CompareButton.Location = New-Object System.Drawing.Size($ExitButton.Left - $ExitButton.Width - 10,100)

$CompareButton.Size = New-Object System.Drawing.Size(75,23)

$CompareButton.Text = "Compare"

$CompareButton.Add_Click({

$SuppliedValue = $objSuppliedVal.Text.ToLower()

$CalculatedValue = $objTextBox.Text.ToLower()

$MsgBoxButtons = New-Object System.Windows.Forms.MessageBoxButtons

$MsgBoxIcon = New-Object System.Windows.Forms.MessageBoxIcon

If ($SuppliedValue -eq $CalculatedValue) {

$MsgBoxButtons = "OK"

$MsgBoxIcon = "Information"

[System.Windows.Forms.MessageBox]::Show("Matched successfully.", "Success", $MsgBoxButtons, $MsgBoxIcon)

}

Else {

$MsgBoxButtons = "OK"

$MsgBoxIcon = "Warning"

[System.Windows.Forms.MessageBox]::Show("Not matched.", "Not matched", $MsgBoxButtons, $MsgBoxIcon)

}

})

$objForm.Controls.Add($CompareButton)

$objForm.Topmost = $true

$objForm.ShowDialog()

# Clear up

$File.Dispose()

All that lot should give you:
A prompt to select the file you want to calculate the hash of

The hash result

And then, if you supply a hash and click the Compare button, it’ll say either

Now I’m sure there are PowerShell gurus out there that could have all this done in 4 lines of code but it was a learning experience so the code is always likely to be a little more verbose than is absolutely necessary.

Feel free to use the code but plug me as a source if you’re going to use the code on your own blog if you wouldn’t mind.

-Lewis
